Senseca UKV-020GKL0025 Flow Meter

RangesFlow Meter UK-020Medium water The details in the table correspond to a vertical inwards flow frombelow.Metering range 5.0 - 50 cm3/min 10.0 - 100 cm3/min 20.0 - 240 cm3/min 0.2 - 3 l/h0.5 - 6 l/h 1.0 - 15 l/h 4.0 - 40 l/h 10.0 - 80 l/hQmax. recommended Type 6 l/min UK.-020G.W0050 UK.-020G.W0100 UK.-020G.W0240UK.-020G.W0003 UK.-020G.W0006 UK.-020G.W0015 UK.-020G.W0040 UK.-020G.W0080Medium air The details in the table correspond to a vertical inwards flow frombelow, with the medium at a temperature of 0 °C and a pre-pressure of 1.013 bar.● Frontal scale imprint ● Optionally valve ● Installation plateCharacteristics A float moves in a transparent conical measurement tube, relativeto the flow. The position of the float depends on the volume flow (weight force versus resistance to flow), and indicates the flow rateon the scaled measurement tube.Metering range 0.04 - 0.5 Nl/min 0.10 - 1.0 Nl/min 0.40 - 5.0 Nl/min 2.50 - 25.0 Nl/minQmax. recommended 0.7 Nl/min 1.2 Nl/min 6.0 Nl/min 30.0 Nl/minType UK.-020G.L0000 UK.-020G.L0001 UK.-020G.L0005 UK.-020G.L0025DimensionsTechnical data Switch Nominal width Process connection Metering range Qmax.Tolerance Pressure resistance Medium temperature Ambient temperature MediaElectrical data Materials medium-contactNon-mediumcontact materials Weight Installation locationwithoutDN 4 female thread 1/8 “ NPT 0.005..25 l/min to 30 l/min ±5 % of full scale valuePN 6 barfor details see table "Ranges"-20..+65 °C -20..+65 °C water, gases none Brass construction:Stainless steel acrylic, glass, construction:1.4305, 1.4310, acrylic, glass, CW614N, NBR 1.4305, 1.4310, FKM acrylic, CW614N, PSvalve: ABS, CW614N 0.13 kg vertical inwards flow from belowdsh_fam_uk-020_en_vs01 V1.03-011
