Senseca CM2K-025.HK.IP65/0282 Flow Switch - Paddle Type

Senseca products, including Senseca CM2K-025.HK.IP65/0282 Flow Switch - Paddle Type, are sourced through parallel import channels and delivered to our customers worldwide with speed and reliability. Even if Senseca CM2K-025.HK.IP65/0282 Flow Switch - Paddle Type is not listed on our website, you are welcome to request a price quote — our team will respond promptly with a tailored offer.FLOWCM2KFlow switchGENERAL CHARACTERISTICS This flow switch is suitable to control the flow in pipes from DN25 toDN200. The simple installation and durability make this instrument suitable for industrial use, and its low cost extends its use to the fieldsof air conditioning and heating. The paddle has a displacement proportional to the flow that invests itself, the displacement istransmitted mechanically to a microswitch.The sensitivity is adjustable by acting on the adjustment screw (•).The switch is equipped with 3 paddles for pipes from DN25 to DN80, a fourth paddle is available for diameters larger than DN 100.● ● ● ● ●Low pressure loss.External calibration.Hermetic separation between the mechanical and electrical parts.Electric head removable and replaceable.SPDT microswitch 250V - 5ATECHNICAL DATADIMENSIONS 1” conical thread UNI 7/1 – DIN 2999Process connection Accuracy Medium temperature Working pressure Average pressure lossWeight 15% F.S.Max. 110°C Max. 25 bar 0,15 bar at max. flow rate 350 gSETTING RANGES DNQ max m3/hD1 mm.25 32 403,6 6 930 39 4150155165247280368110060101150120151200240206Setting ranges m3/h H2OPaddle N.0,9 2,3 2,8 6,5 1,9 11,4 4,8 16,5 7,6 2,7 26,3− − − − − − − − − − −1,0 2,7 3,4 7,5 2,4 13,3 5,7 18,9 8,9 3,5 30,31 1 1 1 1+2 1 1+2 1 1+2 1+2+3 113,3−15,31+26,7−8,41+2+35,4−6,71+2+3+431,0−40,01+2+38,6−15,01+2+3+455,0−71,01+2+316,0−27,01+2+3+4Setting ranges for horizontal mounting and decreasing flow.Reference passage diameter D1Check that the paddle does not touch the bottom of the pipe.If necessary cut it and adjust at the length as indicated.ELECTRICAL DATA Contact Contact ratings Electrical connection Degree of protectionWIRING AND SETTINGS SPDT PlugMicroswitch 250V - 5ADIN 43650AIP 65Adjusting the switch point (•) Lift the safety cover on the electric head andturn the adjustment screw clockwise to increase sensitivity.NOMENCLATURE AND MATERIALS Body Paddle Paddle holder Protection bellow SpringMagnetCM2K – 025HMCM2K – 025HKNickel plated brass S.S. 1.4301 S.S. 1.4571 S.S. 1.4305 NBR S.S. 1.4310 Oxid 300S.S. 1.4571 S.S. 1.4301 S.S. 1.4571 S.S. 1.4305 NBR S.S. 1.4310 Oxid 300We reserve the right to change the data without notice162Paddle 1 Paddle 2 Paddle 3 Paddle 4DN25 DN50 DN80 ≥ DN100BE#081/4-01/2014
