Albrecht Asvn1305 Valve

Asvn1305 ValveQuick-closing ASV valve with 3/2-way solenoid valves and micro limit switches for “Open” and “Closed”. ASV valve version with electro-pneumatic positioner. The safety quick-closing valve is available as a small poppet valve, impressing with its diverse properties. It is designed to prevent hazardous operating conditions and protect the plant. In the event of an auxiliary power failure, the valves close by spring force within 1 second and in the control function within 5 seconds.Areas of use:steamOperating pressure:0 to 40 bar.Operating temperature / Ambient temperature:-20 °C to +400 °C.-20 °C to +80 °C.Other temperatures on request.Valve housing:DIN and ANSI flange connections and welded ends.Housing material:GP240GH (1.0619); P250GH (1.0460);- DING-X6CrNiMo18 10 (1.4408);X6CrNiMoTi17-12-2 (1.4571)- ANSIA105, A216 WCB Special materials Material certification according to EN 10204Albrecht- Automatik GmbH | Industriestraße 12 | 50259 Pulheim | +49 2238 / 9 65 92-0 | [email protected] | www.albrecht-automatik.de2
