Albrecht 68C13DX Revisizon

Areas of use:Heating oil EL, M, S and oils not according to.Operating pressure:max. 24bar max. 28bar max. 32bar max. 40barto +300°C to .+230°C to +200°C to +120°COperating temperature / Ambient temperature:-20 °C to +300 °C.-20 °C to +80 °C.Other temperatures on request.Valve housing:DIN and ANSI flange connections and welded ends.Housing material:- DINGP240GH (1.0619); P250GH (1.0460);G-X6CrNiMo18 10 (1.4408);X6CrNiMoTi17-12-2 (1.4571)- ANSIA105, A216 WCB Special materials Material certification according to EN 10204Albrecht- Automatik GmbH | Industriestraße 12 | 50259 Pulheim | +49 2238 / 9 65 92-0 | [email protected] | www.albrecht-automatik.de2
