Ast CV-8660/S High Pressure Butterfly Control Valve

MATERIALSThe Following tables shows the suggested temperature limits for some of the most common materials.Temperature ranges shown on the tables are representative of the uses established byand refer to this catalogue.Every material may be used for a wider range of temperatures and moreover specific experience leadsto fit these limits for every industrial process.The ASME/ANSI B16.34 standard establishes pressure/temperature limits for the valves flangesdepending on the materials of construction.BODYMINMAXA216WCB-29°C426°CA217WC6-29°C590°CA352 LCB-46°C343°CA 352 LC3-101°C343°CA 217 WC9-29°C590°CA 351 CF8M-267°C816°CA 315 CF8-254°C816°CA 494 M-35-1 (Monel)-200°C482°CTRIMMINMAXAISI 316/AISI 304-267°C550°C (*)AISI 316 L-267°C426°C (*)AISI 630 (17-4 PH)-100°C315°CAISI 410-100°C416°CHastelloy C276-200°C538°CMonel-240°C480°CInconel 625-240°C650°CStellite No. 6-267°C650°C(*) If stellited; without stellite max 315°C.To analyse the use of other materials than shown on the tables please contact9technical department.
